Perforated Solid Wall HDPE Pipes
Engineered to control waterlogging and support efficient subsurface drainage, with customizable perforation patterns for project-specific water-management requirements.
Designed for controlled drainage
Union Pipes Industry manufactures solid-wall perforated pipes from high-density polyethylene (HDPE). The openings allow controlled water intake and conveyance while the solid-wall construction supports demanding buried drainage applications.
Efficient water collection
Perforations collect excess subsurface water and help reduce waterlogging.
Project-specific patterns
Slot or hole dimensions and spacing can be customized to suit project requirements.
UV-stabilized HDPE
Carbon-black-stabilized HDPE provides a robust material solution for outdoor handling and buried service.
Material specifications
The catalogue identifies the following base material properties and reference standards.
Perforation patterns
Four standard arrangements provide different intake distributions around the pipe circumference.
Type A
2-slot pattern
45° slot position; pattern rotated 90° on alternating rows.
Type B
3-slot pattern
Three slots at 120°; pattern rotated 60° on alternating rows.
Type C
8-hole pattern
Eight evenly spaced openings at 45° intervals.
Type D
6-hole pattern
Six evenly spaced openings at 60° intervals.
| Pattern | Openings per row | Nominal spacing | Distribution |
|---|---|---|---|
| Type A | 2 slots | 45° positions | Rotated arrangement |
| Type B | 3 slots | 120° apart | Rotated arrangement |
| Type C | 8 holes | 45° apart | Evenly spaced |
| Type D | 6 holes | 60° apart | Evenly spaced |
Typical applications
Subsurface drainage
Collection and conveyance of water beneath finished ground level.
Waterlogging control
Removal of excess water to support stable site conditions.
Water management
Controlled intake through selected perforation coverage.
Special projects
Customized openings for project-specific hydrogeological requirements.
Need a project-specific configuration?
Contact our technical team to select the perforation pattern, opening dimensions and spacing for your application.
Technical values and pattern geometry are based on the Union Pipes Industry Perforated Solid Wall HDPE Pipe catalogue. Final product configuration is subject to approved project requirements.
